Motors

The SPEEDX2 1303.5 motor is a cutting-edge brushless motor boasting a lightweight and sleek design, efficient heat dissipation, and a distinctive aesthetic.

Featuring a lightweight structure weighing just 6.5g (with a 90mm cable length), this device showcases an exquisite and magnificent outer rotor with a blade design. The elevated propeller platform offers enhanced compatibility with inverted mounted propeller models. It effectively prevents any contact between the high-pitch propeller and the top of the rotor, thus ensuring optimal balance and performance.

To enhance heat dissipation and efficiency while controlling the motor's working temperature, a sizable space is hollowed out to reduce weight. This optimization not only ensures optimal performance but also enhances durability and reliability.

The SPEEDX2 1303.5 motor features a meticulously crafted rotor made from high-quality 7075-T aircraft aluminum. This material not only enhances the strength but also contributes to superior performance and durability.

Experience an unparalleled smooth flying adventure with impeccable magnetic circuit design that ensures stable linearity and remarkable explosive power. Ideal for pilots seeking to construct their own 2" cinewhoop FPV drones, this technology is bound to elevate your aerial pursuits.

GE delivering lightweight, ultra-responsive, highly efficient, and incredibly powerful brushless motors for pilots.

SPECIFICATIONS

Brand Name: GEPRC

Model Number: GEPRC SPEEDX2 1303.5 3800KV/5500KV Motor

Wheelbase: Screws

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Motors

Tool Supplies: Assembly Category

Remote Control Peripherals/Devices: Motor

Recommend Age: 12+y,14+y

RC Parts & Accs: Motors

Quantity: 1 pcs

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Helicopters

Model: SPEEDX2 1303.5-5500KV

• Configuration:9N12P

• Magnet: N52H ARC

• Stator diameter: 13mm

• Stator height: 3.5mm

• Shaft diameter: Φ2mm(in)1.5mm(out)

• Dimension: Φ17.35mm*11.7mm

• Lead wires: 28#AWG 90mm

• Rated voltage (LiPo): 2-4S

• Maximum power: 128.8W

• Maximum current: 8.7A

• Recommended ESC: 35A

• Mounting hole: 9mmx9mm(M2)

• Color: titanium color

• Weight: 6.5g (90MM wire length)

• Suitable models: 2 inch with propeller guard drones or 2.5 inch freestyle drones

Model: SPEEDX2 1303.5-3800KV

• Configuration: 9N12P

• Magnet: N52H ARC

• Stator diameter: 13mm

• Stator height: 3.5mm

• Shaft diameter: Φ2mm(in)1.5mm(out)

• Dimension: Φ17.35mm*11.7mm

• Lead wires: 28#AWG 90mm

• Rated voltage (LiPo): 4-6S

• Maximum power: 139.9W

• Maximunm current: 6.3A

• Recommended ESC: 35A

• Mounting hole: 9mmx9mm(M2)

• Color: titanium color

• Weight: 6.5g (90MM wire length)

• Suitable models: 2 inch with propeller guard drones or 2.5 inch freestyle drones

PACKAGE

1 x SPEEDX2 1303.5 motor
6 x M2*6mm screws
6 x M2*8mm screws

Introducing the all-new iFlight XING E PRO 2306 Brushless Motors! These motors are perfect for racing drones, taking flight performance to a whole new level. Whether it's for speed or stability, the XING series is sure to deliver. With a high-strength 4mm steel shaft, N52SH high-temperature magnets, and 16x16mm hole pattern you know your drone will remain powerful and durable even in the tightest of spaces! Plus, you can rest assured that each part of these efficient motors is crafted with utmost perfection; from single strand copper winding to CNC machined aluminum top and base parts. As a pilot, you need confidence in your machine; that's why with iFlight XING E PRO 2306 Brushless Motors you'll have no problem relying on the power they generate coupled with their exceptional quality.

SPECIFICATIONS

• Configuration: 12N14P

• Stator Diameter:24mm

• Magnets: N52SH Curved

• Bearing Size: 9x4x4

• Shaft Diameter: 4mm / Steel

• Base Mounting Pattern: 16x16mm M3 Thread

• Motor Dimension:29.5x18.7mm

• Weight:33.1g (150mm wires)

• Idle Current @12.6v (Io):2.1A

• Cells (LiPo): 2-6S

• Max Burst Current <10s:55.22A

• Max Power (W) 60s:885.4W

• Internal Resistance (Rm):40.6mΩ

• Motor Wire Length: 150mm / 20AWG

 Since its initial release in 2018, the XING series NextGen motors have established themselves as the new industry standard. What factored into the success - the one-of-a-kind curve, a damping ring for bearing protection or the pairing of titanium alloy shafts with top-notch NSK bearings? After years of imitations and comparisons, it's time for us to elevate the benchmark once again.

The XING motors just got seriously upgraded for smooth, reliable, and powerful performance! The manufactory precision work reaches a new level, sporting faster response time with center slotted N52H curved arc magnets -- a cutting-edge motor design.  Get the locked-in flight feeling you crave with XING2 motors! Quick PID loop translations prevent common FPV translation delays between braking and accelerating. By eliminating this characteristic bottleneck, we are redefining aerial drone performance.

Due to the high quality materials used and the durable joint of bell and shaft, we were able to reduce the magnet air gap and stator lamination to a minimum. Smaller air gaps result in lower reluctance and higher magnetic flux - the magnetic equivalent of current - leading to greater efficiency and power!

Early 2018 we started to put o-rings on the top of the bearings between motor bell and stator. This absorbs impact and tightens the bearing gap to minimize high RPM-induced vibrations after a crash. It can also reduce the axial impact force just enough to keep the bearings smooth and quiet. The new XING series comes equipped with the same high-quality 7075 bells, O-ring bearing protection, and all the other must-have features found in the original design. However, with a fresh new shape and design, it's sleeker and more stylish than ever before.

SPECIFICATIONS

• Model: XING2 2207


• KV: 1855KV / 2755KV (select)

• Version: CW Screw Thread

• Input Voltage: 4S/6S Lipo

• Configuration: 12N14P

• Stator Diameter: 22mm

• Stator Length: 7mm

• Weight: 31.6g with short wire

• Wire length:20AWG 160mm

• Mounting pattern: 16*16mm

PACKAGE

• 1x XING2 2207 Brushless Motor (KV is optional)

• 4xm3*6 screws

• 1xM5 Flanged Nylon Insert Lock Nut

Introducing the Dji Mavic mini arm power motor! Don't miss out on this exclusive replacement part and keep your DJI Mavic mini functioning at its best. Crafted with steel and plastic, you can trust that this power motor will have your drone working like new again. Nothing will stand in your way when you need to fly like a pro with the reliable precision of this power motor. Unlock a world of possibilities and experience something truly special with the Dji Mavic mini arm power motor. It's durable, dependable, and made for the skies - let nothing stop you from taking flight! Don't wait any longer, get your hands on one today and experience something extraordinary!

Package:

Motor * 1/2

SPECIFICATIONS:

Overall dimension: Φ28.5 × 32.5mm

1700KV

Prop mounting shaft diameter: M5
Position of installation hole: 16 × 16mm ， M3
Prop: 5inch ~ 6inch
Bearing ： 4 * 9 * 4
Shaft Diameter: 4mm
Wire size lead: 24AWG × 190mm
Slots / poles: 12N14P
magnetic wire: enameled wire class H 220 ℃
stator Diamter: 22mm
Height of the stator: 7.5 mm
Rated Voltage: 4 ~ 6S (~ 16.8V 25.2V)
peak current : 38.5 A
Maximum power: 924 W

KV: 1800
Prop mounting shaft diameter: M5
Position of installation hole: 16 × 16 mm ， M3
Prop: 5inch ~ 6inch
Bearing ： 4 * 9 * 4
Shaft Diameter: 4mm
size of lead wire: 24AWG × 190mm
Slots / poles: 12N14P
magnetic wire: enameled wire class H 220 ℃
stator Diamter: 22mm
Height of the stator: 7.5 mm
Rated Voltage: 4 ~ 6S (~ 16.8V 25.2V)
Peak current: 42.1A
Maximum power: 1011W

KV: 2450
Installation hole position: 16 × 16 mm, M3
Prop: 5inch ~ 6inch
Bearing ： 4 * 9 * 4
Shaft Diameter: 4mm
size of lead wire: 24AWG × 190mm
Slots / poles: 12N14P
magnetic wire: enameled wire class H 220 ℃
stator Diamter: 22mm
Height of the stator: 7.5 mm
Rated Voltage: 3 ~ 4S (~ 12.6V 16.8V)
Peak current: 44.1A
Maximum Power: 706W

KV: 2650
Position of installation hole: 16 × 16mm ， M3
Prop: 5inch ~ 6inch
Bearing ： 4 * 9 * 4
Shaft Diameter: 4mm
Size lead wire: 24AWG × 190mm
Slots / poles: 12N14P
magnetic wire: enameled wire class H 220 ℃
stator Diamter: 22mm
Height of the stator: 7.5 mm
Rated Voltage: 3 ~ 4S (~ 12.6V 16.8V)
Current peak: 51.2A
Maximum power: 819 W

PACKAGE:

1 x TOKA 2207.5 brushless motor
